Bookwalter Rectal/Trans-Anal Surgery Retractor
$2,199Free Shipping
Obstetrics & Gynecology Retractors
Bookwalter Perineal Surgery Retractor
SKU:RM-BPRS-1
$2,199USD
Free Shipping
The Bookwalter Perineal Surgery Retractor is a table-mounted self-retaining retractor system that provides stable, hands-free exposure during perineal, colorectal, gynecologic and pelvic procedures. Its framework combines a 12″ field post, horizontal bar, vertical extension bar, post couplers and a notched perineal ring with five tilt ratchet mechanisms. A full complement of vaginal posterior, Deaver and malleable blades is included, supplied in a sterilization box.
Product Description
The Bookwalter Perineal Surgery Retractor is a table-mounted self-retaining retractor system designed to provide stable, hands-free exposure during perineal, colorectal, gynecologic and pelvic surgical procedures. Its mounting framework consists of a 12″ (30 cm) field post, two post couplers, a horizontal bar and a 12″ (30 cm) vertical extension bar, giving multiple mounting and positioning options relative to the operating table.
The working frame is formed by a 9½″ × 14½″ (24.1 × 36.8 cm) perineal ring with notches, supported by an 8½″ (21.6 cm) half circle segment. Five multi-angle tilt ratchet mechanisms attach to the ring and allow the angle and depth of each blade to be adjusted independently as the exposure requirement changes.
The included blade configuration covers a range of exposure needs: two vaginal posterior blades, two Deaver blades in 5″ and 3½″ lengths, and six malleable blades in ½″ × 4″, ¾″ × 4″ and 1″ × 5″ sizes. All components are manufactured from non-magnetic, surgical-grade stainless steel and are supplied in a dedicated sterilization box.
The Bookwalter Perineal Surgery Retractor is supplied non-sterile and is reusable and fully autoclavable. The Bookwalter Perineal Surgery Retractor must be cleaned and sterilized according to the healthcare facility's validated procedures before use. Retractor Maker manufactures the system in Sialkot, Pakistan.
Product Specifications
| Specification | Details |
|---|---|
| Intended Use | Provides stable, hands-free exposure during perineal, colorectal, gynecologic, and pelvic surgical procedures with multiple mounting and positioning options. |
| Primary Material | Non-magnetic, surgical-grade stainless steel |
| Configuration | Complete Perineal Surgery Retractor System |
| Mounting System | Field post with horizontal bar, vertical extension bar, post couplers, and notched perineal ring |
| Sterility | Supplied non-sterile (fully autoclavable) |
| Packaging | Supplied in a sterilization box |
| Manufacturer | Retractor Maker |
| Product Condition | Brand new |
| Minimum Order Quantity (MOQ) | 1 Full Set |
Component List
| Quantity | Component | Dimensions / Description |
|---|---|---|
| 1 | Field Post | 12″ (30 cm) |
| 2 | Post Couplers | Standard |
| 1 | Horizontal Bar | Standard |
| 1 | Vertical Extension Bar | 12″ (30 cm) |
| 5 | Tilt Ratchet Mechanisms | Standard Multi-Angle |
| 1 | Half Circle Segments | 8½″ Diameter (21.6 cm) |
| 1 | Perineal Ring with Notches | 9½″ × 14½″ (24.1 × 36.8 cm) |
| 2 | Vaginal Posterior Blades | 1″ × 4½″ (2.5 × 11.4 cm) |
| 1 | Deaver Blade | 1″ × 5″ (2.5 × 12.7 cm) |
| 1 | Deaver Blade | 1″ × 3½″ (2.5 × 8.9 cm) |
| 2 | Malleable Blades | ½″ × 4″ (1.3 × 10.2 cm) |
| 2 | Malleable Blades | ¾″ × 4″ (1.9 × 10.2 cm) |
| 2 | Malleable Blades | 1″ × 5″ (2.5 × 12.7 cm) |
| 1 | Sterilization Box | Protective Case |
Minimum order quantity:1 Full Set.
Frequently Asked Questions
What is included in the complete Bookwalter Perineal Surgery Retractor?
The complete system includes the perineal ring frame and table post assembly, self-retaining ratchet mechanisms, a comprehensive set of rectal, vaginal and St. Mark’s blade varieties, and a dedicated sterilization container for organized processing.
What is the Bookwalter Perineal Surgery Retractor used for?
The Bookwalter Perineal Surgery Retractor is a table-mounted, self-retaining surgical retractor engineered to provide steady, hands-free exposure of deep operative fields. By anchoring directly to the operating table rails and locking blades under mechanical counter-traction, it eliminates assistant muscle fatigue and prevents tissue slip during long procedures.
Which surgical procedures is it for?
This system is indicated for perineal and anorectal procedures, including perineal prostatectomy, rectocele repair and anorectal reconstruction.
What material and finish are used?
Every component is manufactured from non-magnetic, surgical-grade stainless steel. All surfaces are treated with a non-reflective satin finish to suppress glare under intense operating room lighting.
Is it reusable and autoclavable?
Yes. The entire Bookwalter Perineal Surgery Retractor is 100% reusable and fully validated for standard steam autoclave sterilization cycles (pre-vacuum steam at 134°C / 273°F). All mechanical clamps, ratchets and joint connections should be loosened or disassembled prior to cleaning and autoclaving.
Can components and blades be ordered separately?
Yes. Hospitals, clinics and distributors can purchase individual replacement parts — including specific blade depths, ratchet mechanisms, frame rings, post couplers and storage cases — as open-stock catalog items without needing to buy a complete system.
Can custom blade dimensions or private-label markings be ordered?
Yes. Because Retractor Maker is a direct manufacturer, we provide custom blade modifications (such as extended depths or specialty curves), bespoke frame sizing, and custom laser etching for hospital asset tracking or OEM branding.
What is the standard lead time and delivery timeframe for orders?
For in-stock instruments, orders take 5 business days to process and inspect, followed by 7 business days for worldwide delivery. For back-order or custom-manufactured systems, production takes 17 to 20 business days, followed by 9 business days for delivery. Full tracking details are supplied upon dispatch.
How to Order
- 01
Open the product you want to order
Open the product page for the surgical retractor, blade or component you are interested in.
- 02
Click Order by Email or Order on WhatsApp
Choose whichever contact method is more convenient for you.
- 03
Discuss your order directly with Retractor Maker
Discuss quantity, availability, shipping and payment details directly with our team.
