Bookwalter StrongArm Basic General Retractor System
SKU:RM-BSABGRS-1
$1,499USD
Free Shipping
The Bookwalter StrongArm Basic General Retractor System is a compact, self-retaining retractor set for open general surgery. A height-adjustable top mount StrongArm PLUS Holder with heavy-duty rail clamp supports a medium oval ring, and four multi-angle tilt ratchets hold a Balfour blade, a Harrington blade and two malleable blades. Manufactured from non-magnetic, surgical-grade stainless steel and supplied non-sterile in a sterilization box.
Product Description
The Bookwalter StrongArm Basic General Retractor System is a self-retaining retractor system mounted on the StrongArm PLUS Holder and Positioner. The holder is attached to the operating table and holds the retracting frame in place, providing stable, hands-free surgical exposure during open general surgical procedures.
The mounting system consists of a height-adjustable, articulated top mount StrongArm PLUS Holder together with a heavy-duty rail clamp compatible with the table rail. The holder carries a medium oval ring measuring 10½″ × 14½″ (26.7 × 36.8 cm), which is positioned over the incision and locked at the working height and angle required.
Four multi-angle tilt ratchet mechanisms clamp to the ring and hold each blade at the selected depth and inclination. The basic blade complement comprises one Balfour blade at 2⅝″ × 3″ (6.7 × 7.6 cm), one Harrington blade at 1″ × 5⅝″ × 2½″ (2.5 × 14.3 × 6.4 cm) and two malleable blades at 2″ × 6″ (5.1 × 15.2 cm).
All components are manufactured from non-magnetic, surgical-grade stainless steel. The Bookwalter StrongArm Basic General Retractor System is brand new, reusable and fully autoclavable, and is supplied non-sterile — it must be cleaned and sterilized in line with the healthcare facility's validated procedures before use. The Bookwalter StrongArm Basic General Retractor System is supplied in a sterilization box that protects and organizes the components. Retractor Maker manufactures the system in Sialkot, Pakistan and supplies it directly to hospitals, surgeons and distributors, with a minimum order quantity of one full set.
Product Specifications
| Specification | Details |
|---|---|
| Intended Use | Designed to provide stable, hands-free surgical exposure during open general surgical procedures using the StrongArm PLUS Holder and Positioner. |
| Primary Material | Non-magnetic, surgical-grade stainless steel |
| Configuration | Complete StrongArm Basic General Retractor System |
| Mounting System | Height-adjustable StrongArm PLUS Holder with heavy-duty rail clamp |
| Sterility | Supplied non-sterile (fully autoclavable) |
| Packaging | Supplied in a sterilization box |
| Manufacturer | Retractor Maker |
| Product Condition | Brand new |
| Minimum Order Quantity (MOQ) | 1 Full Set |
Component List
| Quantity | Component | Dimensions / Description |
|---|---|---|
| 1 | Top Mount StrongArm PLUS Holder | Height-Adjustable / Articulated |
| 1 | Oval Ring, Medium | 10½″ × 14½″ (26.7 × 36.8 cm) |
| 1 | Heavy Duty Rail Clamp | Table Rail Compatible |
| 4 | Tilt Ratchet Mechanism | Multi-Angle |
| 1 | Balfour Blade | 2⅝″ × 3″ (6.7 × 7.6 cm) |
| 1 | Harrington Blade | 1″ × 5⅝″ × 2½″ (2.5 × 14.3 × 6.4 cm) |
| 2 | Malleable Blades | 2″ × 6″ (5.1 × 15.2 cm) |
| 1 | Sterilization Box | Protective Case |
Minimum order quantity:1 Full Set.
Frequently Asked Questions
What is included in the complete Bookwalter StrongArm Basic General Retractor System?
The complete system includes the StrongArm split-ring frame and table post assembly, self-retaining ratchet mechanisms, a comprehensive set of Richardson, Kelly, Deaver and Balfour blade varieties, and a dedicated sterilization container for organized processing.
What is the Bookwalter StrongArm Basic General Retractor System used for?
The Bookwalter StrongArm Basic General Retractor System is a table-mounted, self-retaining surgical retractor engineered to provide steady, hands-free exposure of deep operative fields. By anchoring directly to the operating table rails and locking blades under mechanical counter-traction, it eliminates assistant muscle fatigue and prevents tissue slip during long procedures.
Which surgical procedures is it for?
This system is indicated for general laparotomy and abdominal procedures, including colectomy, liver resection, gastric surgery and splenectomy.
What material and finish are used?
Every component is manufactured from non-magnetic, surgical-grade stainless steel. All surfaces are treated with a non-reflective satin finish to suppress glare under intense operating room lighting.
Is it reusable and autoclavable?
Yes. The entire Bookwalter StrongArm Basic General Retractor System is 100% reusable and fully validated for standard steam autoclave sterilization cycles (pre-vacuum steam at 134°C / 273°F). All mechanical clamps, ratchets and joint connections should be loosened or disassembled prior to cleaning and autoclaving.
Can components and blades be ordered separately?
Yes. Hospitals, clinics and distributors can purchase individual replacement parts — including specific blade depths, ratchet mechanisms, frame rings, post couplers and storage cases — as open-stock catalog items without needing to buy a complete system.
Can custom blade dimensions or private-label markings be ordered?
Yes. Because Retractor Maker is a direct manufacturer, we provide custom blade modifications (such as extended depths or specialty curves), bespoke frame sizing, and custom laser etching for hospital asset tracking or OEM branding.
What is the standard lead time and delivery timeframe for orders?
For in-stock instruments, orders take 5 business days to process and inspect, followed by 7 business days for worldwide delivery. For back-order or custom-manufactured systems, production takes 17 to 20 business days, followed by 9 business days for delivery. Full tracking details are supplied upon dispatch.
How to Order
- 01
Open the product you want to order
Open the product page for the surgical retractor, blade or component you are interested in.
- 02
Click Order by Email or Order on WhatsApp
Choose whichever contact method is more convenient for you.
- 03
Discuss your order directly with Retractor Maker
Discuss quantity, availability, shipping and payment details directly with our team.
