Bookwalter GYN Magrina Pelvic Surgery Retractor System
$1,499Free Shipping
Obstetrics & Gynecology Retractors
Bookwalter GYN Retractor System
SKU:RM-BGRS-1
$1,699USD
Free Shipping
The Bookwalter GYN Retractor System is a table-mounted self-retaining retractor designed to provide stable, hands-free surgical exposure during gynecological and vaginal procedures. The complete system combines a field post, horizontal support, notched perineal ring, adjustable tilt ratchets and dedicated vaginal retractor blades.
Product Description
The Bookwalter GYN Retractor System is a table-mounted self-retaining retractor designed to provide stable, hands-free exposure during gynecological and vaginal procedures. Its modular framework combines a field post, horizontal support bar, notched perineal ring and adjustable tilt ratchet mechanisms to hold selected blades around the operative field.
The GYN configuration includes a 9½″ × 14½″ notched perineal ring, four multi-angle tilt ratchet mechanisms, vaginal lateral and posterior blades, and two Deaver blades. The complete set is supplied in a dedicated sterilization box for organized storage and processing.
The Bookwalter GYN Retractor System is made from non-magnetic, surgical-grade stainless steel and is supplied non-sterile. It is designed to be reusable and autoclavable and should be cleaned and sterilized before use according to the healthcare facility's validated procedures.
Retractor Maker supplies the Bookwalter GYN Retractor System directly to hospitals, distributors and other B2B customers.
Product Specifications
| Specification | Details |
|---|---|
| Intended Use | Designed to provide stable, hands-free surgical exposure during gynecological and vaginal procedures using a table-mounted self-retaining retractor system. |
| Primary Material | Non-magnetic, surgical-grade stainless steel |
| Configuration | Complete Gynecology Retractor System |
| Mounting System | Field post with horizontal bar and post coupler |
| Ring Configuration | Notched perineal ring |
| Sterility | Supplied non-sterile (fully autoclavable) |
| Packaging | Supplied in a sterilization box |
| Manufacturer | Retractor Maker |
| Product Condition | Brand new |
| Minimum Order Quantity (MOQ) | 1 Full Set |
Component List
| Quantity | Component | Dimensions / Description |
|---|---|---|
| 1 | Field Post | 12″ (30 cm) |
| 1 | Post Coupler | Standard |
| 1 | Horizontal Bar | Standard |
| 4 | Tilt Ratchet Mechanisms | Multi-Angle |
| 1 | Perineal Ring with Notches | 9½″ × 14½″ (24.1 × 36.8 cm) |
| 2 | Vaginal Lateral Blades | 1″ × 3″ (2.5 × 7.6 cm) |
| 1 | Vaginal Posterior Blade | 1″ × 4½″ (2.5 × 11.4 cm) |
| 1 | Deaver Blade | 1″ × 5″ (2.5 × 12.7 cm) |
| 1 | Deaver Blade | 1″ × 3½″ (2.5 × 8.9 cm) |
| 1 | Sterilization Box | Protective Case |
Minimum order quantity:1 Full Set.
Frequently Asked Questions
What is included in the complete Bookwalter GYN Retractor System?
The complete system includes the ring frame and table post assembly, self-retaining ratchet mechanisms, a comprehensive set of vaginal, St. Mark’s, Deaver and Balfour blade varieties, and a dedicated sterilization container for organized processing.
What is the Bookwalter GYN Retractor System used for?
The Bookwalter GYN Retractor System is a table-mounted, self-retaining surgical retractor engineered to provide steady, hands-free exposure of deep operative fields. By anchoring directly to the operating table rails and locking blades under mechanical counter-traction, it eliminates assistant muscle fatigue and prevents tissue slip during long procedures.
Which surgical procedures is it for?
This system is indicated for gynecological and pelvic procedures, including hysterectomy, myomectomy, pelvic mass excision and sacrocolpopexy.
What material and finish are used?
Every component is manufactured from non-magnetic, surgical-grade stainless steel. All surfaces are treated with a non-reflective satin finish to suppress glare under intense operating room lighting.
Is it reusable and autoclavable?
Yes. The entire Bookwalter GYN Retractor System is 100% reusable and fully validated for standard steam autoclave sterilization cycles (pre-vacuum steam at 134°C / 273°F). All mechanical clamps, ratchets and joint connections should be loosened or disassembled prior to cleaning and autoclaving.
Can components and blades be ordered separately?
Yes. Hospitals, clinics and distributors can purchase individual replacement parts — including specific blade depths, ratchet mechanisms, frame rings, post couplers and storage cases — as open-stock catalog items without needing to buy a complete system.
Can custom blade dimensions or private-label markings be ordered?
Yes. Because Retractor Maker is a direct manufacturer, we provide custom blade modifications (such as extended depths or specialty curves), bespoke frame sizing, and custom laser etching for hospital asset tracking or OEM branding.
What is the standard lead time and delivery timeframe for orders?
For in-stock instruments, orders take 5 business days to process and inspect, followed by 7 business days for worldwide delivery. For back-order or custom-manufactured systems, production takes 17 to 20 business days, followed by 9 business days for delivery. Full tracking details are supplied upon dispatch.
How to Order
- 01
Open the product you want to order
Open the product page for the surgical retractor, blade or component you are interested in.
- 02
Click Order by Email or Order on WhatsApp
Choose whichever contact method is more convenient for you.
- 03
Discuss your order directly with Retractor Maker
Discuss quantity, availability, shipping and payment details directly with our team.
